95U SERIES POLYURETHANE TUBING

95U SERIES POLYURETHANE TUBING

1/4 OD WELD TUBE WHITE

MicroWeld™ PolyurethaneTubing - 95FR is ideal for low to medium pressure air and water supply lines where weld spatter protection is required.
Availability: In stock
SKU
95FR-4-WHT-0500
Lead Time
7
The 95FR Series Weld Spatter Resistant Tubing is lightweight and extremely flexible. It is an ideal option for low to medium pressure air and water supply lines where weld spatter protection is required. The double wall design has a flame resistant jacket made from a material that meets the UL94 V-0 standard and the tubing offers excellent hydrolytic stability, ensuring the tube will not degrade when used in water based applications. Parflex 95FR tubing is available in multiple colors for easy line identification.

Markets:
• Industrial

Features/Benefits:
• UL-94 V0 Flame resistant jacket material
• Exellent flexibility
• Abrasion resistant
• Moisture resistant
• Weld Spatter resistant
• Grease and Oil resistant
• Silicone and Halogen free

Applications:
• Pneumatic Systems
• Robotic Welding
• End-of-Arm Tooling
• General Robotics
• General Automation

Technical Specifications:
• Working and burst pressures rated at 73°F /23°C
More Information
Maximum Operating Pressure 16.5 bar, 1.65 MPa, 240 psi
Division Parflex Division
Compatible Fitting 68PLM
Application Robotics, Pneumatic Systems, Welding, Automation
Maximum Operating Temperature 165 °F, 75 °C
Minimum Operating Temperature -40 °F, -40 °C
Minimum Bend Radius 3/4 inch, 19 mm
Cover Material Proprietary Material
Product Type Fractional, Inch
Weight Parker 0.042 lb/ft, 0.062 kg/m
Tube Material Polyurethane
Tube Outside Diameter 1/4 inch, 6.4 mm
Color White
Cover Color White
Tube Inside Diameter 3.0 mm, 0.160 inch
Minimum Burst Pressure 50 bar, 720 psi, 5.0 MPa
Length per Package 500 ft
Standard Pack Qty (ft) 500.0
Diameter 8.6 mm, 0.340 inch
Order Size -4
