| Maximum Operating Pressure | 350 bar, 35.0 MPa |
|---|---|
| Division | Polymer Hose Division Europe |
| Application | Antifreeze Solutions, Diesel Fuels, Air Brake Systems |
| Product Style | Female JIC 37° - Swivel |
| Specifications Met | ISO 12151-5-SWE |
| Product Type | Crimp Fittings No-Skive |
| Body Material | Steel |
| Shape | Elbow 45°, Elbow 45° Short Drop |
| Materials of Construction | Steel |
| Hose Inside Diameter | -6 |
| Connection 2 Size | 9/16"-18 inch Thread |
| Connection 1 Size | -6 (Size), 3/8 inch Hose I.D., 9.5 mm Hose I.D. |
| Brand | Parker |
| Connection 2 Type | Female, Swivel, JIC 37°, Female JIC 37°/SAE 45° Dual Flare - Swivel |
| For Fluid Type | Lubricants (Oils), Petroleum Hydraulic Fluids (Petroleum Base), Fuels (Diesel) |
| Hex Size | 11/16 inch (see drawing legend W) |
| Industry | Industrial Manufacturing Equipment, Off-road Machinery |
| Connection 1 Type | Hose |
| Configuration | Hose to Port |
| Technology | Fluid & Gas Handling |
| Hose I.D. (size) | -6 |
| Port Size | 6 mm |
| Port Type | DKJ |
| Connection Length | 47 mm (see drawing legend B) |
| Fitting Length | 69 mm (see drawing legend A) |
| Port Connection | 3/8" |
| Connection Size | 9/16"-18 inch Thread |
| Coating | Chromium 6 Free-plated |
| Drop Length | 11 mm (see drawing legend E) |
