| Media | Water, Fuels - Check fuel type with our catalogue chart., Lubricants (Oils), Coolants (Glycol), Air (General Industrial Air), Petroleum Hydraulic Fluids (Petroleum & Water-Glycol Base) |
|---|---|
| Maximum Operating Pressure | 155 bar, 15.5 MPa, 2250 psi |
| Division | Polymer Hose Division Europe |
| Compatible Fitting | 48 Series |
| Application | Machine Tools, Glass Industry |
| Hose Inner Tube Material | Synthetic Rubber |
| Inside Diameter | 3/8 inch, 9.5 mm |
| Maximum Operating Temperature | 100 °C (Water 85°C / Air 70°C), 212 °F (Water 185°F / Air 158°F) |
| Minimum Operating Temperature | -40 °F, -40 °C |
| Minimum Bend Radius | 130 mm |
| Product Style | No-Skive 2TE |
| Outside Diameter | 19 mm |
| Specifications Met | SAE 100R1, Type AT |
| Cover Material | Galvanized Steel Wire |
| Design Factor | 4:1 |
| Hose Reinforcement Material | 1 Braid of High Tensile Steel Wire |
| Product Type | Specialty Hose, Hydraulic Hose |
| Weight Parker | 0.54 kg/m, 0.36 lb/ft |
| Materials of Construction | Rubber |
| Brand | Parker |
| Industry | Industrial Manufacturing Equipment, Transportation, Off-road Machinery |
| Technology | Fluid & Gas Handling |
| Hose I.D. (size) | -6 |
| Hose Cover Type | Galvanised steel wire |
