Parker's 244 hose is a refrigerant hose that has a pressure range of 350-500 PSI, designed for the rigorous requirements of bus and transit applications.
Availability: In stock
SKU
244-16
Lead Time
55
Parker's 244 hose is a refrigerant hose that has a pressure range of 350-500 PSI, designed for the rigorous requirements of bus and transit applications. The 244 hose is designed, built, and tested to meet SAE J2064 B Class I performance specifications. Sizes range from 7/8” to 1-3/8” in diameter to fit the requirements of air conditioning systems.

Markets:
• Transportation

Features/Benefits:
• 350-500 PSI working pressure in different sizes
• Built for a long service life
• Resists moisture ingression
• Parkrimp compatible
• Excellent effusion rate

Applications:
• Refrigerant

Compatible Fittings:
• 26 series fittings
More Information
Media Coolants
Maximum Operating Pressure 500 psi, 3.5 MPa
Division Hose Products Division
Compatible Fitting 26 Series
Application Refrigerant 134a
Hose Inner Tube Material Butyl Rubber
Inside Diameter 22 mm, 7/8 inch
Maximum Operating Temperature 257 °F, 125 °C
Minimum Operating Temperature -30 °C, -22 °F
Minimum Bend Radius 7-1/2 inch, 190 mm
Outside Diameter 31 mm, 1.230 inch
Specifications Met SAE J2064, Type B Class I
Hose Reinforcement Material 1 Braid of Fiber, 1 Braid of Steel Wire
Weight Parker 0.76 kg/m, 0.51 lb/ft
Nominal Hose Inside Diameter 22 mm
Hose I.D. (size) -16
Hose Cover Type Standard Cover
