| Media | Hydraulic |
|---|---|
| Maximum Operating Pressure | 3000 psi |
| Division | Quick Coupling Division |
| Application | Hydraulics, Breakaway Sleeve, Connect Under Pressure |
| Maximum Operating Temperature | 250 °F |
| Minimum Operating Temperature | -40 °F |
| Specifications Met | ISO 5675 |
| Body Material | Steel |
| Connection Type | UNF |
| Body Size | 1/2 inch |
| Thread Size | Female |
| Seal Material | Nitrile |
| Lock Type | Locking Balls |
| Flow Rate | 12 gal/min |
| Plating Type | Zinc with Clear Trivalent Chromate |
| Coupling Half | Coupler |
| Valve Type | Poppet |
| Brand | Pioneer |
| Connection Thread Size (inch) | 1/2 - 14 |
| Sleeve Type | Manual push pull sleeve with lower sleeve spring force |
| Mounting Position | Left hand – yellow grip |
