COUPLING 3/8"MP FMX3/8" MP FM

Medium Pressure adapters have a 58/60 degree coned and threaded tubing design with a maximum working pressure rating of 20,000 psi.
Availability: In stock
SKU
5Y5Y-6-6C
Lead Time
0
Parker's Medium Pressure adapters provide maximum flow of liquids and gases at elevated pressures. They are ideal for waterblast, pressure testing and hydraulic test stand applications of 20,000 psi or less.

Markets:
• Waterblast
• Hydraulics

Features/Benefits:
• An industry standard for use at elevated pressures
• Large orifice allows for maximum flow of liquids and gases
• Suitable for repetitive assembly and disassembly

Applications:
• Hydraulic systems and waterblast applications with working pressures up to 20,000 psi
More Information
Maximum Operating Pressure 20000 psi, 138 MPa
Division Parflex Division
Materials of Construction Stainless Steel AISI 316
Connection 2 Size 9/16"-18 inch
Connection 1 Tube Outside Diameter 3/8" (O.D.)
Connection 1 Size 9/16"-18 inch
Connection 2 Tube Outside Diameter 3/8" (O.D.)
Connection 2 Type Female, UNF Thread, Medium Pressure, Female Medium Pressure
Hex Size 0.75 inch, 19.05 mm
Connection 1 Type UNF Thread, Female, Medium Pressure, Female Medium Pressure
Overall Length 1.75 inch, 44.45 mm
