| Division | Polymer Hose Division Europe |
|---|---|
| Product Style | High Pressure Tube Nipple UNF – LH Thread |
| Shape | Straight |
| Connection Thread Size | 3/8"-24 |
| Materials of Construction | Stainless Steel |
| Fitting Type | Y4 |
| Length (inch) | 3.4" |
| Connection Type | UNF-LH |
| Maximum Working Pressure (psi) | 58000 psi |
| Hose I.D. (inch) | 5/32" |
| Hose I.D. (size) | -25 |
| Hose I.D. | DN 4 |
| Hose I.D. (mm) | 4 mm |
| Length (mm) | 86 mm |
| Maximum Working Pressure (MPa) | 400.0 MPa |
