DIFFUSER3/4"NPT50L/MIN
DIFFUSER2"NPT4541/MIN
DIFFUSER1-1/2"NPT227L/MIN
Installing a diffuser in a hydraulic reservoir is a simple change that can make a dramatic difference in system efficiency.
With special concentric tubes designed with discharge holes 180o opposed, fluid aeration, foaming and reservoir noise are reduced. Pump life is also extended by reducing cavitation to the pump inlet.
More Information
Division
Engine Mobile Hydraulic and Fuel Filtration Division
Weight Parker
1.23 lbs (0.56 kg)
Length
178.0 mm, 7 inch
Flow Rate
60.0 gal/min, 227.0 L/min
Hex Size
5.56 inch, 65.0 mm
Diameter
3.4 inch, 86.0 mm
Thread
1.5 in NPT
